108mm White Primed Universal FD30 Fire Door Lining
Click an image to enlarge.
Images for illustrative purposes only.
Untrenched White Primed FD30 Door Lining Kit
This untrenched head door frame kit is ideal for imperial and metric FD30 fire doors up to 940mm wide by 2077mm high. A simple construction can be achieved by notching or trenching the head at the required position to allow the jambs to be fixed in place.
This interior door frame is suitable for 110mm thick walls (or wider walls with plastered reveals) , the door liner is 30mm thick, and supplied with loose door stops and intumescent fire and smoke seal.
108mm White Primed Universal FD30 Fire Door Lining
108mm White Primed Universal FD30 Fire Door Lining Specifications:
Brand: Excel Joinery
Frame height: 2077 mm
Frame width: 1000 mm
Finish: White Primed
Leadtime: 2-10 Working Days
Material: MDF
PEFC Accredited: yes
Product Type: Door Frame
Cat No: DFPGRSFD108FS
